Apple MacBook Pro

Size and weight

• Height: 0.95 inch (2.41 cm)

• Width: 14.35 inches (36.4 cm)

• Depth: 9.82 inches (24.9 cm)

• Weight: 5.6 pounds (2.54 kg)1

Connections and expansion

• MagSafe power port

• Gigabit Ethernet port

• FireWire 800 port (up to 800 Mbps)

• Two USB 2.0 ports (up to 480 Mbps)

• Thunderbolt port (up to 10 Gbps)

• Audio line in

• Audio line out

• SDXC card slot

• Kensington lock slot

Communications

• Wi-Fi wireless networking2 (based on IEEE 802.11n specification); IEEE 802.11a/b/g compatible

• Bluetooth 2.1 + EDR (Enhanced Data Rate) wireless technology

• 10/100/1000BASE-T Gigabit Ethernet (RJ-45 connector)

Audio

• Stereo speakers with subwoofers

• Omnidirectional microphone (located under left speaker grille)

• Audio line in minijack (digital/analog)

• Audio line out/headphone minijack (digital/analog)

• Support for Apple iPhone headset with microphone

Environmental Status Report

MacBook Pro is designed with the following features to reduce its environmental impact:

• Highly recyclable aluminum and glass enclosure

• Mercury-free LED-backlit display

• Arsenic-free display glass

• BFR-free

• PVC-free3

• Energy Efficient Ethernet

• Reduced packaging volume

• Meets ENERGY STAR Version 5.2 requirements

• Rated EPEAT Gold4

Display

• 15.4-inch (diagonal) LED-backlit glossy or optional antiglare widescreen display with support for millions of colors

• Supported resolutions: 1440 by 900 (native), 1280 by 800, 1152 by 720, 1024 by 640, and 800 by 500 pixels at 16:10 aspect ratio; 1024 by 768, 800 by 600, and 640 by 480 pixels at 4:3 aspect ratio; 1024 by 768, 800 by 600, and 640 by 480 pixels at 4:3 aspect ratio stretched; 720 by 480 pixels at 3:2 aspect ratio; 720 by 480 pixels at 3:2 aspect ratio stretched

Graphics and video support

• AMD Radeon HD 6750M graphics processor with 512MB of GDDR5 memory on 2.2GHz configuration; or AMD Radeon HD 6770M graphics processor with 1GB of GDDR5 memory on 2.4GHz configuration

• Intel HD Graphics 3000 with 384MB of DDR3 SDRAM shared with main memory5

• Automatic graphics switching

• Dual display and video mirroring: Simultaneously supports full native resolution on the built-in display and up to 2560 by 1600 pixels on an external display, both at millions of colors

• FaceTime HD camera

• Thunderbolt port

Thunderbolt digital video output

• Native Mini DisplayPort output

• DVI output using Mini DisplayPort to DVI Adapter (optional)

• VGA output using Mini DisplayPort to VGA Adapter (optional)

• Dual-link DVI output using Mini DisplayPort to Dual-Link DVI Adapter supports 30-inch Apple Cinema HD Display (optional)

• HDMI audio and video output using a third-party Mini DisplayPort to HDMI Adapter

Input

• Full-size backlit keyboard with 78 (U.S.) or 79 (ISO) keys, including 12 function keys and 4 arrow keys (inverted “T” arrangement)

• Multi-Touch trackpad for precise cursor control; supports inertial scrolling, pinch, rotate, swipe, three-finger swipe, four-finger swipe, tap, double-tap, and drag capabilities

Processor and memory

• 2.2GHz or 2.4GHz quad-core Intel Core i7 processor with 6MB shared L3 cache; or optional 2.5GHz quad-core Intel Core i7 processor with 8MB shared L3 cache

• 4GB (two 2GB SO-DIMMs) of 1333MHz DDR3 memory; two SO-DIMM slots support up to 8GB

Storage

• 500GB or 750GB 5400-rpm Serial ATA hard drive; optional 750GB 5400-rpm hard drive, 750GB 7200-rpm hard drive, or 128GB, 256GB, or 512GB solid-state drive6

• 8x slot-loading SuperDrive (DVD±R DL/DVD±RW/CD-RW)

• Maximum write: 8x DVD-R, DVD+R; 4x DVD-R DL (double layer), DVD+R DL (double layer), DVD-RW, DVD+RW; 24x CD-R; 10x CD-RW

• Maximum read: 8x DVD-R, DVD+R, DVD-ROM; 6x DVD-ROM (double layer DVD-9), DVD-R DL (double layer), DVD+R DL (double layer), DVD-RW, DVD+RW; 24x CD

Battery and power7

• up to 7 hrs wireless web

• Built-in 77.5-watt-hour lithium-polymer battery

• 85W MagSafe Power Adapter with cable management system

• MagSafe power port

Electrical and operating requirements

• Line voltage: 100V to 240V AC

• Frequency: 50Hz to 60Hz

• Operating temperature: 50° to 95° F (10° to 35° C)

• Storage temperature: -13° to 113° F (-24° to 45° C)

• Relative humidity: 0% to 90% noncondensing

• Maximum operating altitude: 10,000 feet

• Maximum storage altitude: 15,000 feet

• Maximum shipping altitude: 35,000 feet

Acoustic Performance

DECLARED NOISE EMISSIONS in accordance with ISO 9296

1. LWAd is the statistical upper-limit A-weighted sound power level (rounded to the nearest 0.1 B).

2. LpAm is the mean A-weighted sound pressure level measured at the operator position (rounded to the nearest dB).

3. 1 B (bel) = 10 dB (decibel).

What’s in the box

• MacBook Pro

• Display cleaning cloth

• 85W MagSafe Power Adapter, AC wall plug, and power cord

• Printed and electronic documentation

Software

• OS X Lion (includes Mail, Address Book, iCal, the Mac App Store, iTunes, Safari, Time Machine, FaceTime, Photo Booth, Mission Control, Launchpad, AirDrop, Resume, Auto Save, Versions, Quick Look, Spotlight, QuickTime, and more)

• iLife (includes iPhoto, iMovie, and GarageBand)

15-inch Configurations
